FPC connectors are still widely understood by many people. FPC connectors are flexible printed circuit board connectors. Generally speaking, PCB connectors made of soft materials (folding and bending materials) are used. The connection of the LCD display to the drive circuit (PCB).

Such as FPC connector package size and FPC connector specifications and other aspects of knowledge, FPC connector is currently divided into 0.3mm, 0.5mm, 1.0mm, etc., the connector package size is also different, then today is small The next step is to explain the package size and packaging method of the two commonly used FPC connectors.

For connectors with small pitch of FPC connector package, the package is required to protect the coplanarity of the connector terminals and the positive position of the terminal arrangement. Generally, there are two kinds of packaging methods, one is pvc tube. The package is another package. For example, the FPC connector package has a smaller pitch.

In this small series, it is recommended that you use a tape carrier package. The pvc tube package has poor protection performance for small-pitch FPC connectors, and the SMT process requires manual placement of the product on the pcb, which increases the off-line process in the assembly. , seriously affecting the efficiency of production.

If the carrier tape package is selected according to the surface mounting electronic components such as ICs, the size of the product package is designed according to the shape of the product. The tape carrier can protect the product from damage and can be combined with other electronic devices in the SMT process. The component is subjected to the automatic patch soldering process without unnecessary processes and equipment, which improves the assembly efficiency of the pcb.
